一进一出 电压电流输入隔离器
CZ2083  一进一出 电压电流输入隔离器
7.6mm超薄外壳，节省安装空间。功耗低至0.5W，多种量程选择，可现场设置。
通道数:
一进一出
输入:
0~20mA
4~20mA
0~5V
0~10V
2~10V
1~5V
输出:
0~20mA
0~5V
0~10V
1~5V
2~10V
4~20mA
供电方式:
24VDC
电源连接方式:
端子供电
CZ2083
Product details
Technichal Data
Download
点击咨询
contrast
enquire

一进一出 电压电流输入隔离器一进一出 电压电流输入隔离器

CHENZHU EPLAN CZ2083.edz

Technichal Data
"Hey, let's talk about your concerns~"
I Want To Ask Questions
Cancel
Submit
Select All
No.
Type
Name/Description
Language
Download
1
Technical drawings
CHENZHU EPLAN CZ2083.edz
Chinese
2
Manual
CZ2083 技术规格书.pdf
Chinese
3
Manual
CZ2083 使用说明书-4.4.pdf
Chinese
